Larger Aperture Starlight CCTV Lens YT-6048P-A1

  • Top Quality Cctv Lens
  • Wide Angle Dfov 200 Degree Ttl13mm F2.6 Fisheye Lens
  • larger aperture starlight lens for low light condition
  • Item No :

    YT-6048P-A1
  • Sensor :

    IMX335
  • F/NO. :

    1.6
  • EFL :

    1.32mm
  • Optical TTL :

    13.41
  • Thread Size :

    M12*P0.5
  • FOV(H/V/D) :

    200°/176°/200°
  • Structure :

    3G3P+1IR



YT-6048P-A1: Wintop Optics' Premier Large Aperture Lens



know more about YT-6048P-A1 CCTV Lens parameters
MAX Img-Circle (mm)
Ø4.2
EFL (mm) 1.32
F/NO. 1.6
Optical TTL 13.41
Mechanical TTL 13.41
BACK FOCAL LENGTH 2.35
FLANGE BACK LENGTH 1.30
TV DISTORTION <-45%
REL ATIVE ILLUMINATION  ≥60%
CRA 14°
Pixel Size (μm) 2.0μm*2.0μm
Storage At Temperature
-40°C~+85°C
Recent Camera Distance 0.2
Infrared

No

WAVEIENGTH

@420~610nm Tavg≥90%

T=50% @650土10nm

Waterproof Level

IP67

STRUCTURE

3G3P+1IR



Experience Unparalleled Clarity with the YT-6048P-A1 Lens


Wintop Optics proudly presents the YT-6048P-A1, a cutting-edge large aperture lens designed to redefine visual acuity in low-light surveillance and automotive imaging systems. With an impressive F1.6 aperture, this lens captures more light, ensuring crisp, brightly illuminated images even in the most challenging lighting conditions. Whether it's the still of night or the dimness of dusk, the YT-6048P-A1 stands as a vigilant guardian, providing clarity when it matters most.



Precision Focus for Instantaneous Response


Crafted with a 1.32mm optical focal length and an optical total length of 13.41mm, the YT-6048P-A1 is equipped with a high-speed autofocus system. This feature allows for swift and accurate targeting, essential for real-time monitoring and rapid response scenarios. Whether it's a vehicle's camera system or a security surveillance setup, this lens ensures that every detail is captured with pinpoint precision.

High-Resolution Imaging with IMX335 Compatibility


Embrace the clarity of 2 million HD pixels with the YT-6048P-A1's seamless integration with the IMX335 sensor (2592*1944). As technology advances, Wintop Optics' large aperture lenses deliver high-resolution imaging that captures fine details with ease. From license plate numbers to facial features, this lens is pivotal in enhancing the effectiveness of security surveillance systems.


Vivid Color Reproduction and Depth Control


The YT-6048P-A1 excels in color reproduction, offering natural and accurate hues that bring images to life. Its ability to control depth of field results in sharp subjects with softly blurred backgrounds, drawing attention to key elements within the surveillance frame. This feature significantly improves recognition accuracy and safety, making it an invaluable asset in security and automotive applications.

Extended Field of View for Comprehensive Coverage


With a wide-angle function that boasts a field of view exceeding 200 degrees both diagonally and horizontally, the YT-6048P-A1 covers a vast expanse of visual real estate. This is particularly beneficial for panoramic automotive surveillance and security monitoring, minimizing blind spots and enhancing surveillance efficiency.

Durable and Reliable Design


Featuring a robust M12*P0.5 thread and an IP67 rating for water and dust resistance, the YT-6048P-A1 is engineered for durability and reliability. Its design and construction consider the rigours of long-term operation and diverse environmental conditions, making it an essential component for surveillance systems that demand unwavering performance.



The YT-6048P-A1 large aperture lens from Wintop Optics is not just a lens; it's a statement of commitment to excellence in imaging technology. It stands at the forefront of innovation, offering unparalleled clarity, precision, and durability. Choose the YT-6048P-A1 for a surveillance and automotive imaging experience that is nothing short of revolutionary.
