YT-7200-B1:High Definition Low Distortion Lens for Automotive & Intelligent Vision Applications
Know More About YT-7200-B1 Automotive & Intelligent Vision Lens Parameters
|
| Max Img-Circle(mm) |
∅7.6
|
| EFL(mm) |
12.99±5%
|
| F/NO. |
1.6±5%
|
| Optical TTL(mm) |
20.75±0.3 |
| Mechanical TTL(mm) |
20.10±0.3 |
| Back Focal Length(mm) |
3.52
|
| TV Distortion |
<-0.67% |
| Relative Illumination |
>65% |
| CRA |
13.6° |
| FOV(H/V/D) |
25°/20°/32° |
| Storage at Temperature |
-40℃/+80℃
|
| Recent Camera Distance |
0.2M
|
| Infrared |
No
|
| Wavelength |
@430~615nm Tavg＞93%
@650nm±10nm T=50%
|
| Dust Level |
IP69K
|
| Structure |
5G+1IR
|
YT-7200-B1 High Definition Low Distortion Lens for Automotive & Intelligent Vision Applications
The YT-7200-B1 is a professional low distortion M12 lens designed for automotive vision systems, AI intelligent imaging devices, and industrial monitoring applications. Featuring a 12.9mm focal length, F1.65 large aperture, and near zero distortion optical performance, this high-definition lens delivers precise imaging quality for advanced machine vision and automotive camera systems.
Built with a compact and durable optical structure, the YT-7200-B1 is optimized for intelligent transportation systems, ADAS cameras, driver monitoring systems, electronic rearview mirrors, and high-precision industrial vision equipment. Its ultra low distortion imaging capability makes it especially suitable for applications requiring accurate image recognition, object measurement, and environmental analysis.
The lens adopts a professional 5G+IR optical structure and supports stable imaging performance under challenging lighting and environmental conditions. With IP69K protection and excellent optical clarity, the YT-7200-B1 provides reliable performance for both indoor and outdoor intelligent imaging projects.
Ultra Low Distortion Lens for Precision Imaging
One of the core advantages of the YT-7200-B1 is its ultra low distortion optical design. With TV distortion controlled to below 0.67%, this lens delivers near zero distortion imaging performance, helping maintain straight image lines and accurate object proportions.
Compared with traditional wide angle automotive lenses, the YT-7200-B1 significantly reduces image deformation, making it ideal for:
- ADAS forward-facing cameras
- Driver monitoring systems (DMS)
- Electronic mirror cameras (CMS)
- License plate recognition systems
- Intelligent traffic monitoring cameras
- Machine vision inspection systems
- Industrial measurement equipment
- Smart parking systems
The near distortion-free image output improves AI recognition accuracy and enhances the reliability of intelligent visual processing systems.
12.9mm Telephoto Lens for Long-Distance Monitoring
Designed with a 12.9mm focal length, the YT-7200-B1 functions as a compact telephoto M12 lens capable of capturing distant targets with excellent image detail.
This makes it highly suitable for applications such as:
- Forward collision warning cameras
- Long-range vehicle monitoring systems
- Smart transportation cameras
- Highway surveillance systems
- Intelligent traffic enforcement devices
- Industrial automation cameras
The telephoto optical design helps improve target recognition performance at longer distances while maintaining stable image sharpness and clarity.
F1.65 Large Aperture for Excellent Low-Light Performance
The YT-7200-B1 features an F1.65 large aperture design that enhances light transmission and improves imaging performance in low-light environments.
For automotive cameras operating at night, underground parking lots, tunnels, or rainy weather conditions, the large aperture allows the sensor to capture brighter and clearer images with reduced noise.
This low-light automotive camera lens is ideal for:
- Night vision driving assistance systems
- Intelligent surveillance cameras
- Vehicle black box cameras
- AI monitoring devices
- Smart city imaging systems
The combination of high transmittance and low distortion helps deliver stable image quality in both daytime and nighttime scenarios.
Reliable Automotive Lens for Harsh Environments
Built for demanding automotive and industrial applications, the YT-7200-B1 supports operation in extreme temperatures ranging from -40°C to +80°C.
With IP69K dustproof and waterproof protection, the lens can withstand harsh outdoor environments including rain, dust, vibration, and high-pressure cleaning conditions.
This industrial-grade automotive camera lens is suitable for:
- Commercial vehicle cameras
- Truck and bus camera systems
- Construction machinery vision systems
- Agricultural vehicle cameras
- Intelligent robotics equipment
- Outdoor AI monitoring systems
Its robust optical and mechanical structure ensures long-term reliability for mission-critical imaging applications.
Compact M12 Lens Design for Easy System Integration
The YT-7200-B1 adopts a standard M12 mount structure, allowing easy integration into compact camera modules and embedded vision systems.
The compact lens structure supports flexible installation in various intelligent devices including:
- Automotive electronic systems
- Smart AI cameras
- Industrial embedded vision equipment
- Intelligent transportation devices
- Robotics and automation systems
Its professional optical engineering design ensures consistent image performance and production stability for OEM and ODM projects.
Why Choose Wintop Optics YT-7200-B1
- high resolution automotive lens
- 12.9mm telephoto M12 lens
- Ultra low distortion / near zero distortion imaging
- F1.65 large aperture for low-light environments
- IP69K waterproof and dustproof protection
- Stable optical performance for AI vision systems
- Suitable for ADAS, DMS, CMS, and industrial cameras
- OEM/ODM optical customization support
Wintop Optics specializes in automotive camera lenses, AI vision lenses, machine vision optics, and intelligent imaging solutions. With advanced optical manufacturing capability, strict quality control systems, and professional customization services, we provide reliable lens solutions for global automotive, industrial, and smart vision projects.
