AA gluing OX01F10 1/4'' Dfov 200° auto electronic mirror lenses YT-7054-D1-A

The IP69 Vehicle Surveillance Lens For Driving Safety

High-Resolution Imaging:

Crafted to work seamlessly with the OX01F10 sensor for a 1/4" inch sensor, the YT-7054-D1-A delivers 2 million clear pixels with a lens height of 4.08mm. This ensures sharp, detailed images for a comprehensive view of your surroundings.

Compact Design for Versatility:

Featuring an optical focal length (EFL) of 0.98mm and an optical total length (TTL) of 13.83±0.3mm, the lens is compact yet powerful. With a Back Focal Length of 2.58mm and a Flange Back Length of 1.71mm, it is designed for easy integration into various vehicle surveillance systems.

Exceptional Night Vision:

The F2.0 aperture lens ensures that the YT-7054-D1-A excels in low-light conditions, providing clear and detailed night vision. It's perfect for round-the-clock monitoring, ensuring that nighttime surveillance is as effective as during the day.

Panoramic Field of View:

The lens offers a panoramic field of view with a diagonal angle exceeding 200 degrees, a horizontal angle of 195 degrees, and a vertical angle of 126 degrees. This expansive coverage makes it ideal for vehicle surround view cameras, rearview cameras, smart device cameras, network surveillance, smart home monitoring, and robotic surveillance.

Extreme Environmental Durability:

With a storage temperature range of -40℃ to +85℃ and an IP69 rating for waterproof and dustproof capabilities, the YT-7054-D1-A is built to withstand the most challenging conditions. The Chief Ray Angle of 24 degrees and a relative illuminance of over 53.5% ensure consistent performance across different lighting environments.

Advanced Lens Construction:

The lens features a AA gluing 12mm mount diameter and a 14mm lens cover diameter, constructed with a hybrid of glass and plastic lenses for optimal clarity and durability. The inclusion of a 650nm IR cut filter ensures accurate color reproduction and enhanced image quality.

The YT-7054-D1-A is the epitome of versatility and performance, offering a complete 360° view with high-resolution clarity and robust durability. It's the ultimate choice for applications that demand comprehensive surveillance and unwavering reliability. Experience the power of total visibility with the YT-7054-D1-A – your all-weather, all-encompassing vehicle surveillance solution.
