10MP 20mm Focal Length High Definition Industrial Inspection Lens YT-4861

You are in:

/ Home /

Industrial Camera Lens

/ 10MP 20mm Focal Length High Definition Industrial Inspection Lens YT-4861
Industrial Inspection Lens

10MP 20mm Focal Length High Definition Industrial Inspection Lens YT-4861

  • The YT-4861 is a high-performance digital camera with an image resolution of 10 megapixels (10MP).
  • The camera lenses can be paired with image sensor technology to capture clear, detailed images.
  • It also comes with a range of powerful features that make it ideal for a variety of application scenarios, including industrial inspection, monitoring systems, medical imaging, and more.

  • Item No :

    YT-4861

  • Sensor :

    1" （Φ16、12.8x9.6）

  • F/NO. :

    F2.0--16

  • EFL :

    20mm

  • Optical TTL :

    66.03mm

  • FOV(H/V/D) :

    H/V 1" 27.20° x 20.82° 2/3" 18.30° x 14.36° 1/1.8" 15.06° x 11.51° 1/2" 13.30° x 10.15°

  • Structure :

    Aluminum alloy (anode black) +9G

  • Mount :

    C-Mounts

  • Resolution :

    10Mega Pixel

  • M.O.D :

    0.25m

  • Distortion :

    1"（-0.7%） 1/2"（-0.5%） 1/3"(-0.15%)

  • Zoom :

    -
Inquiry now
Category
Parameters
Model No
YT-4861
Focal Length
20mm
Format
1" （Φ16、12.8x9.6）
D/fˊ
F2.0--16
Mount
C-Mounts
H/V
1"             27.20° x 20.82°
2/3"         18.30° x 14.36°
1/1.8"      15.06° x 11.51°
1/2"         13.30° x 10.15°
Back Focal Length
17.53mm
Optical length
66.03mm
Iris type
 Manual /Lock (W/Lock)
MTF
10Mega Pixel
M.O.D
0.25m
Dimension
Φ37.00x51.80
Weight
137.0g
Distortion
1"（-0.7%） 1/2"（-0.5%） 1/3"(-0.15%)
Structure
 Aluminum alloy (anode black) +9G
Remarks
UV M34.0x0.5P

High resolution images: The YT-4861 delivers high quality images at a resolution of 10 megapixels (10MP), ensuring that detailed images are captured.

Advanced image sensor: The use of advanced image sensor technology to provide superior image quality and photographic performance, adapt to different light conditions.

Powerful features: The camera is equipped with a variety of features, including autofocus, white balance adjustment, image enhancement, etc., to meet the needs of different applications.

A variety of application scenarios: suitable for industrial testing, monitoring systems, medical imaging and other applications, can provide clear and accurate image data support.

Reliability and durability: The YT-4861 is manufactured with high quality materials and reliable processes, providing excellent durability and stability for continuous operation in harsh environments.
